European-style frame straighteners feature precise positioning, robust structure and compatibility with various vehicle models.The electric hydraulic pump is easy to operate, powerful and low-failure. It enables 360° stretching with 5-ton single tower pull, high efficiency, 2500kg capacity for most cars. Vertical platform (min 120mm) eases access; customizable. ISO 9001:2015 certified.
• High quality electric-hydraulic pump, powerful, and low failure rate;
• True 360 degree pulling, 5 tons pulling capacity per tower, strong and effective;
• 2500 kg lifting capacity, applicable to most sedan cars;
• Parallel-lifting platform, with minimum 120 mm height, easy to drive on and off;
• Platform dimensions, tower quantity, and pulling capacity are all customizable;
• ISO 9001: 2015 certified
Type | Standard Size |
Platform Material | Rectangular Tube |
Platform Dimension | 3440x850x120~1300mm |
Loading Method | Parallel |
Loading Capacity | 2500kg |
Pulling Capacity | 5tons per tower |
Pulling Range | 360°around platform |
Power Unit | Electric-hydraulic pump |
Working Voltage | 220/380V |
Hydraulic Pressure | 70MPa |
